Chromda – Serverless screenshots

Chromda is an AWS Lambda function for serverless capturing screenshots of websites.

Multiple sources

• SNS topics
• SQS queues
• CloudWatch scheduled events
• API Gateway proxy

Configurable

• Capture full page, viewport or specific DOM element
• Exclude DOM elements (useful for ads or other unwanted content)
• Override styles

Quick start

Provided you already have AWS credentials for Serverless, do:

git clone https://github.com/luisfarzati/chromda
cd chromda
git submodule update --init
npm install

Edit the serverless.yml file and change the example bucket name with one of your own:

# serverless.yml
custom:
  s3Bucket: <your bucket name>

Deploy the function into your AWS account:

npm run deploy

Open the AWS Lambda Console and create the following test event:

{
  "source": "aws.events",
  "time": "1970-01-01T00:00:00Z",
  "detail": {
    "url": "https://www.nytimes.com"
  }
}

Click Test, wait a few seconds (it might take around 8-10 secs), then you should see a response like:

{
  "url": "https://<your bucket name>.s3.amazonaws.com/<uuid>.png"
}

Usage

Invocation

The function accepts different kind of events, extracting the data from the proper body attribute as follows:

Options

{
  // required
  "url": "https://google.com",

  // optional - valid options: page, viewport, element
  // default: viewport
  "capture": "page",

  // selector of element to capture
  // required if capture: element
  "selector": ".container",

  // optional - S3 key for the image file
  // default: uuid()
  "s3key": "test.png",

  // optional - selectors of elements to exclude
  "exclude": [".ad", "video"],

  // optional - styles to override
  // see Puppeteer.addStyleTag
  "styles": [
    {
      "content": "body { color: #f00; }"
    }
  ],

  // optional - puppeteer options
  "puppeteer": {
    // see Puppeteer.goto options
    "navigation": {
      "timeout": 30000,
      "waitUntil": ["domcontentloaded", "networkidle2"]
    },
    // see Puppeteer.screenshot options
    "screenshot": {
      "type": "jpeg",
      "quality": 50,
      "omitBackground": false
    },
    // viewport size, overrides env defaults
    "viewport": {
      "width": 1200,
      "height": 2000
    }
  }
}

Environment Variables

Deploy

# serverless.yml

# ...
custom:
  s3Bucket: <your bucket name>

provider:
  # ...
  layers:
    # Replace <version> with the latest version of chrome-aws-lambda-layer
    # It depends on the region you are deploying.
    # https://github.com/shelfio/chrome-aws-lambda-layer#available-regions
    - arn:aws:lambda:${self:provider.region}:764866452798:layer:chrome-aws-lambda:<version>

functions:
  captureScreenshot:
    # ...
    environment:
      # configure the environment variables
      VIEWPORT_WIDTH: "1920"
      VIEWPORT_HEIGHT: "1200"
      # ...
    events:
      # add any of the supported event source(s) you want to use
      # the provided example uses SNS
      - sns:
          arn: !Ref chromdaTopic
          topicName: ${self:custom.snsTopic}

resources:
  # following the example, we provision an SNS topic
  chromdaTopic:
    Type: AWS::SNS::Topic
    Properties:
      TopicName: ${self:custom.snsTopic}

X-Ray

AWS X-Ray support is provided and there are segments for Puppeteer navigation and screenshot:
