Kilas - WhatsApp Gateway API

🚀 Modern, Fast & Reliable WhatsApp Gateway Built with Baileys

Powerful WhatsApp Gateway with beautiful dashboard, multi-session support, and comprehensive REST API

Features • Quick Start • API Documentation • Docker • n8n Integration

⚠️ Disclaimer

This is an unofficial WhatsApp API implementation. This project is not affiliated with, authorized, maintained, sponsored or endorsed by WhatsApp or any of its affiliates or subsidiaries. This is an independent and unofficial software. Use at your own risk.

Important Notes:

Using this software may violate WhatsApp's Terms of Service
Your WhatsApp account could be banned for using unofficial clients
This project is for educational and development purposes only
The developers are not responsible for any misuse or damage caused by this software

✨ Features

🎨 Beautiful Dashboard

Modern UI/UX with vibrant gradients and glassmorphism effects
Real-time monitoring via WebSocket connections
Multi-session management - Handle multiple WhatsApp accounts
Live event logging - See all activities in real-time
Built-in API Tester - Test all endpoints directly from dashboard
QR Code Scanner - Easy WhatsApp authentication

🔌 Comprehensive API

✅ 17+ REST API Endpoints for complete WhatsApp automation
✅ Send Messages - Text, images, documents, locations, and more
✅ Quote/Reply Messages - Reply to specific messages in groups or private chats
✅ Typing Indicator - Show/hide typing status programmatically
✅ Group Management - Create groups, manage participants
✅ Contact Management - Fetch and manage contacts
✅ Status Updates - Post WhatsApp status programmatically
✅ Webhook Support - Receive real-time events with selective filtering
✅ File Upload, Base64 & URL - Flexible media handling (3 methods)

🛡️ Enterprise Ready

🔒 Optional API Key Authentication - Secure your endpoints
🌐 CORS Configuration - Flexible cross-origin settings
💾 Auto-Save Media - Automatically save incoming media files
📊 Session Persistence - Sessions survive server restarts
🐳 Docker Support - Easy deployment with Docker Compose
📝 Comprehensive Logging - Track all activities with Pino logger

🗄️ SQLite Data Persistence (NEW)

💾 Persistent Storage - All dashboard data stored in SQLite database
📤 Outgoing Messages - Track all sent messages with status (pending/sent/delivered/read)
📡 Webhook History - Webhook logs persist across server restarts
⚡ Live Events - Events history saved and survives page refresh
🔍 Message Detail Modal - View full message content, Message ID, and API response
⏱️ Real-time Status Updates - See message delivery status (✓ sent, ✓✓ delivered, ✓✓ read)
📊 Full Pager Navigation - First, Prev, Next, Last with page info (Page X of Y)
🏠 Zero-Config - SQLite database auto-creates on startup
🐳 Docker Volume - Data persists across container restarts

🔗 Integration Support

🤖 n8n Workflow Automation - Official n8n community node available
📦 Easy Installation - Install via @dickyermawan/n8n-nodes-kilas
⚡ No-Code Automation - Build WhatsApp workflows visually in n8n
🔄 Seamless Integration - Connect Kilas with 400+ n8n integrations

📸 Screenshots

Login Page

Modern login interface with gradient design

Live Events & Logs

Real-time event logging with WebSocket connection

Device Management

Multi-session WhatsApp device management with QR code scanner

API Playground

Built-in API tester to test all endpoints directly from dashboard

Webhook Configuration

Configure webhooks with selective event filtering

🚀 Quick Start

Prerequisites

Node.js >= 18.0.0
npm or yarn
Docker (optional, for containerized deployment)

Installation

Option 1: Manual Installation

# Clone the repository
git clone https://github.com/dickyermawan/kilas.git
cd kilas

# Install dependencies
npm install

# Configure environment variables
cp .env.example .env
# Edit .env with your preferred settings

# Start the server
npm start

Option 2: Using Docker Compose (Recommended)

# Clone the repository
git clone https://github.com/dickyermawan/kilas.git
cd kilas

# Create .env file
cp .env.example .env
# Edit .env with your preferred settings

# Start with Docker Compose
docker compose up -d

# View logs
docker compose logs -f

First Steps

Access Dashboard: Open http://localhost:3000/dashboard
Login: Use credentials from .env (default: admin/admin123)
Create Session: Click "New Session" and scan QR code with WhatsApp
Start Using: Your WhatsApp is now connected! 🎉

🐳 Docker Deployment

Option 1: Using Pre-built Image from Docker Hub (Recommended)

The fastest way to deploy Kilas is using the pre-built image from Docker Hub:

1. Create docker-compose.yml:

services:
  kilas:
    image: dickyermawan/kilas:latest
    container_name: kilas-gateway
    restart: unless-stopped
    ports:
      - "3001:3001"
    environment:
      - PORT=3001
      - ADMIN_USERNAME=admin
      - ADMIN_PASSWORD=admin123
      - API_KEY=admin123
      - CORS_ORIGIN=*
    volumes:
      # Named volumes for automatic permission handling
      - sessions_data:/app/sessions
      - media_data:/app/media
      - db_data:/app/data

volumes:
  sessions_data:
    driver: local
  media_data:
    driver: local
  db_data:
    driver: local

2. Start the container:

# Pull and start
docker compose up -d

# View logs
docker compose logs -f

# Check status
docker compose ps

3. Access the dashboard:

Open http://localhost:3001/dashboard in your browser.

Default credentials:

Username: admin
Password: admin123

⚠️ IMPORTANT: Change ADMIN_PASSWORD and API_KEY in docker-compose.yml for production!

Option 2: Build from Source

If you want to build the image yourself:

# Clone the repository
git clone https://github.com/dickyermawan/kilas.git
cd kilas

# Create .env file
cp .env.example .env
# Edit .env with your settings (PORT=3001 by default)

# Build and start
docker compose up -d --build

# View logs
docker compose logs -f

Configuration

All settings are configured via .env file:

# Server Configuration
PORT=3001  # Default port for both host and container

# Admin Credentials
ADMIN_USERNAME=admin
ADMIN_PASSWORD=admin123

# API Authentication
API_KEY=admin123

# CORS Configuration
CORS_ORIGIN=*

To change port: Edit PORT in .env and restart:

docker compose down
docker compose up -d

Data Persistence

Session, media, and database data are stored in named volumes:

sessions_data: WhatsApp session files
media_data: Uploaded media files
db_data: SQLite database (outgoing messages, webhook history, live events)

Benefits:

✅ Automatic permission handling (no manual chown needed)
✅ Data persists across container restarts
✅ Data persists even if container is removed
✅ Works on all platforms (Windows, Linux, Mac)

Data is safe during:

docker compose restart  # ✅ Data preserved
docker compose down && docker compose up -d  # ✅ Data preserved
docker compose pull && docker compose up -d  # ✅ Data preserved

Data will be lost if:

docker compose down -v  # ❌ Removes volumes (don't use -v flag!)
docker volume rm kilas_sessions_data  # ❌ Manually deletes volume

Backup & Restore

Backup sessions:

docker run --rm -v kilas_sessions_data:/data -v $(pwd):/backup alpine tar czf /backup/sessions-backup.tar.gz -C /data .

Restore sessions:

docker run --rm -v kilas_sessions_data:/data -v $(pwd):/backup alpine tar xzf /backup/sessions-backup.tar.gz -C /data

Docker Commands

# Start containers
docker compose up -d

# View logs
docker compose logs -f

# Stop containers
docker compose down

# Restart containers
docker compose restart

# Update to latest image
docker compose pull
docker compose up -d

# Access container shell
docker exec -it kilas-gateway sh

# Remove all data (CAUTION: deletes sessions!)
docker compose down -v

Environment Variables

Variable	Description	Default
`PORT`	Server port	`3000`
`ADMIN_USERNAME`	Dashboard login username	`admin`
`ADMIN_PASSWORD`	Dashboard login password	`admin123`
`API_KEY`	API authentication key (leave empty to disable)	`admin123`
`CORS_ORIGIN`	CORS allowed origins (* for all, or comma-separated domains)	`*`
`SESSION_DIR`	Directory for session data	`./sessions`
`MEDIA_DIR`	Directory for media files	`./media`
`DATA_DIR`	Directory for SQLite database	`./data`

🤖 n8n Integration

Kilas has official support for n8n - the powerful workflow automation platform. Build WhatsApp automation workflows visually with no code required!

Installation

Install the Kilas community node in your n8n instance:

# In your n8n installation directory
npm install @dickyermawan/n8n-nodes-kilas

Or install via n8n UI:

Go to Settings → Community Nodes
Click Install
Enter: @dickyermawan/n8n-nodes-kilas
Click Install

Features

✅ Send Messages - Text, images, documents, locations
✅ Quote/Reply - Reply to specific messages
✅ Typing Indicator - Control typing status
✅ Session Management - Create and manage WhatsApp sessions
✅ Webhook Trigger - Receive WhatsApp events in real-time
✅ Group Management - Create groups, manage participants
✅ Contact Operations - Fetch and manage contacts

Quick Start

Add Kilas Credentials
- Node: Kilas API
- Base URL: http://localhost:3001
- API Key: Your configured API key
Create Workflow
- Trigger: Kilas Webhook (receive messages)
- Action: Kilas (send reply)

Example Workflow

Webhook Trigger → Filter → Kilas Send Message

Use Cases

📱 Customer Support Bot - Auto-reply to customer inquiries
🔔 Notifications - Send alerts from any system to WhatsApp
📊 CRM Integration - Sync WhatsApp messages with your CRM
🤖 Chatbot - Build intelligent chatbots with AI integration
📅 Appointment Reminders - Automated scheduling notifications

Resources

n8n Node Package: @dickyermawan/n8n-nodes-kilas
n8n Documentation: n8n.io/docs
Workflow Templates: Coming soon!

📚 API Documentation

Authentication

All API endpoints (except /api/auth/login) require authentication via API key in the header:

x-api-key: your_secret_api_key

To disable authentication, set API_KEY= (empty) in .env.

📨 Messages API

Send Text Message

Endpoint: POST /api/messages/send-text

PHP Example:

<?php
$data = [
    'sessionId' => 'MySession',
    'chatId' => '628123456789',  // or '[email protected]'
    'text' => 'Hello from Kilas! 🚀'
];

$ch = curl_init('http://localhost:3000/api/messages/send-text');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

$result = json_decode($response, true);
print_r($result);
?>

Response:

{
  "success": true,
  "message": "Message sent"
}

Send Quote/Reply Message

Endpoint: POST /api/messages/send-text

Reply to a specific message by providing the quotedMessageId.

Request Body:

{
  "sessionId": "MySession",
  "chatId": "628123456789",
  "text": "This is a reply to your message",
  "quotedMessageId": "3EB0123456789ABCDEF"
}

PHP Example:

<?php
$data = [
    'sessionId' => 'MySession',
    'chatId' => '628123456789',
    'text' => 'This is a reply!',
    'quotedMessageId' => '3EB0123456789ABCDEF'  // Message ID to quote
];

$ch = curl_init('http://localhost:3001/api/messages/send-text');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Response:

{
  "success": true,
  "message": "Message sent"
}

Note: Get message ID from webhook events or message logs.

Start Typing Indicator

Endpoint: POST /api/messages/typing/start

Show "typing..." indicator in the chat.

Request Body:

{
  "sessionId": "MySession",
  "chatId": "628123456789"
}

PHP Example:

<?php
$data = [
    'sessionId' => 'MySession',
    'chatId' => '628123456789'
];

$ch = curl_init('http://localhost:3001/api/messages/typing/start');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Response:

{
  "success": true,
  "message": "Typing indicator started"
}

Stop Typing Indicator

Endpoint: POST /api/messages/typing/stop

Stop "typing..." indicator in the chat.

Request Body:

{
  "sessionId": "MySession",
  "chatId": "628123456789"
}

PHP Example:

<?php
$data = [
    'sessionId' => 'MySession',
    'chatId' => '628123456789'
];

$ch = curl_init('http://localhost:3001/api/messages/typing/stop');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Response:

{
  "success": true,
  "message": "Typing indicator stopped"
}

Note: Typing indicator auto-stops after ~30 seconds if not manually stopped.

Check Message Status

Endpoint: GET /api/messages/status/:messageId

Check delivery status of a sent message (pending/sent/delivered/read).

URL Parameters:

messageId: The message ID returned when sending a message

PHP Example:

<?php
$messageId = '3EB0ABC123XYZ'; // Message ID from send response

$ch = curl_init("http://localhost:3001/api/messages/status/{$messageId}");
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Response:

{
  "success": true,
  "messageId": "3EB0ABC123XYZ",
  "status": "read",
  "sessionId": "MySession",
  "recipient": "628123456789",
  "messageType": "text",
  "createdAt": "2025-12-26T07:30:00.000Z",
  "updatedAt": "2025-12-26T07:35:00.000Z"
}

Status Values: | Status | Description | |--------|-------------| | pending | Message queued, not yet sent | | sent | Message sent to WhatsApp server (✓) | | delivered | Message delivered to recipient (✓✓) | | read | Message read by recipient (✓✓ blue) |

Send Image

Endpoint: POST /api/messages/send-image

Method 1: File Upload (Multipart)

PHP Example:

<?php
$ch = curl_init('http://localhost:3000/api/messages/send-image');

$postData = [
    'sessionId' => 'MySession',
    'chatId' => '628123456789',
    'caption' => 'Check out this image!',
    'image' => new CURLFile('/path/to/image.jpg', 'image/jpeg', 'image.jpg')
];

curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, $postData);
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Method 2: Base64 (JSON)

PHP Example:

<?php
$imageData = file_get_contents('/path/to/image.jpg');
$base64Image = base64_encode($imageData);

$data = [
    'sessionId' => 'MySession',
    'chatId' => '628123456789',
    'caption' => 'Image from base64',
];

$ch = curl_init('http://localhost:3000/api/messages/send-image');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Method 3: URL (Baileys Native)

Send image directly from URL - Baileys downloads and sends automatically.

PHP Example:

<?php
$data = [
    'sessionId' => 'MySession',
    'chatId' => '628123456789',
    'imageUrl' => 'https://example.com/image.jpg',
    'caption' => 'Image from URL'
];

$ch = curl_init('http://localhost:3001/api/messages/send-image');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Send Document

Endpoint: POST /api/messages/send-document

Method 1: File Upload

PHP Example:

<?php
$ch = curl_init('http://localhost:3000/api/messages/send-document');

$postData = [
    'sessionId' => 'MySession',
    'chatId' => '628123456789',
    'caption' => 'Important document',
    'document' => new CURLFile('/path/to/document.pdf', 'application/pdf', 'document.pdf')
];

curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, $postData);
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Method 2: Base64

PHP Example:

<?php
$documentData = file_get_contents('/path/to/document.pdf');
$base64Document = base64_encode($documentData);

$data = [
    'sessionId' => 'MySession',
    'chatId' => '628123456789',
    'caption' => 'Document from base64',
    'filename' => 'invoice.pdf',
    'mimetype' => 'application/pdf',
    'document' => 'data:application/pdf;base64,' . $base64Document
];

$ch = curl_init('http://localhost:3000/api/messages/send-document');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Method 3: URL (Baileys Native)

Send document directly from URL - Baileys downloads and sends automatically.

PHP Example:

<?php
$data = [
    'sessionId' => 'MySession',
    'chatId' => '628123456789',
    'documentUrl' => 'https://example.com/document.pdf',
    'filename' => 'invoice.pdf',
    'mimetype' => 'application/pdf',
    'caption' => 'Document from URL'
];

$ch = curl_init('http://localhost:3001/api/messages/send-document');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Send Location

Endpoint: POST /api/messages/send-location

PHP Example:

<?php
$data = [
    'sessionId' => 'MySession',
    'chatId' => '628123456789',
    'latitude' => -6.200000,
    'longitude' => 106.816666,
    'address' => 'Jakarta, Indonesia'
];

$ch = curl_init('http://localhost:3000/api/messages/send-location');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

👥 Sessions API

Get All Sessions

Endpoint: GET /api/sessions

PHP Example:

<?php
$ch = curl_init('http://localhost:3000/api/sessions');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

$sessions = json_decode($response, true);
print_r($sessions);
?>

Response:

{
  "success": true,
  "sessions": [
    {
      "id": "MySession",
      "status": "connected",
      "user": {
        "id": "628123456789",
        "name": "My WhatsApp"
      }
    }
  ]
}

Create New Session

Endpoint: POST /api/sessions/create

PHP Example:

<?php
$data = ['sessionId' => 'NewSession'];

$ch = curl_init('http://localhost:3000/api/sessions/create');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Delete Session

Endpoint: DELETE /api/sessions/:id

PHP Example:

<?php
$sessionId = 'MySession';

$ch = curl_init("http://localhost:3000/api/sessions/$sessionId");
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_CUSTOMREQUEST, 'DELETE');
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

👨‍👩‍👧‍👦 Groups API

Get All Groups

Endpoint: GET /api/groups/:sessionId

PHP Example:

<?php
$sessionId = 'MySession';

$ch = curl_init("http://localhost:3000/api/groups/$sessionId");
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

$groups = json_decode($response, true);
print_r($groups);
?>

Create Group

Endpoint: POST /api/groups/create

PHP Example:

<?php
$data = [
    'sessionId' => 'MySession',
    'subject' => 'My New Group',
    'participants' => ['628123456789', '628987654321']
];

$ch = curl_init('http://localhost:3000/api/groups/create');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

📇 Contacts API

Get All Contacts

Endpoint: GET /api/contacts/:sessionId

PHP Example:

<?php
$sessionId = 'MySession';

$ch = curl_init("http://localhost:3000/api/contacts/$sessionId");
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

$contacts = json_decode($response, true);
print_r($contacts);
?>

📢 Status API

Post Status Update

Endpoint: POST /api/status/post/text

PHP Example:

<?php
$data = [
    'sessionId' => 'MySession',
    'text' => 'My Status Update 🚀',
    'backgroundColor' => 0xff1a1f3a,
    'font' => 1
];

$ch = curl_init('http://localhost:3000/api/status/post/text');
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

🔔 Webhook API

Configure Webhook

Endpoint: POST /api/webhook/:sessionId

PHP Example:

<?php
$sessionId = 'MySession';

$data = [
    'webhookUrl' => 'https://your-webhook-url.com/endpoint',
    'events' => [
        'connection.update',
        'messages.upsert',
        'messages.update'
    ]
];

$ch = curl_init("http://localhost:3000/api/webhook/$sessionId");
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'Content-Type: application/json',
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Available Events:

connection.update - Connection status changes
messages.upsert - New messages received
messages.update - Message updates (read receipts, edits)
messages.delete - Deleted messages
presence.update - User presence (online/offline)
chats.upsert - New chats
chats.update - Chat updates
contacts.upsert - Contact updates
groups.upsert - New groups
group-participants.update - Group participant changes
call - Incoming calls

Webhook Payload Structure:

{
  "event": "messages.upsert",
  "sessionId": "MySession",
  "timestamp": "2024-01-01T12:00:00.000Z",
  "data": {
    "type": "notify",
    "messages": [{...}],
    "isGroup": false,           // true if message is from a group
    "chatType": "private"       // 'private' or 'group'
  }
}

Get Webhook Configuration

Endpoint: GET /api/webhook/:sessionId

PHP Example:

<?php
$sessionId = 'MySession';

$ch = curl_init("http://localhost:3000/api/webhook/$sessionId");
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Test Webhook

Endpoint: POST /api/webhook/:sessionId/test

PHP Example:

<?php
$sessionId = 'MySession';

$ch = curl_init("http://localhost:3000/api/webhook/$sessionId/test");
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

Delete Webhook

Endpoint: DELETE /api/webhook/:sessionId

PHP Example:

<?php
$sessionId = 'MySession';

$ch = curl_init("http://localhost:3000/api/webhook/$sessionId");
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_CUSTOMREQUEST, 'DELETE');
curl_setopt($ch, CURLOPT_HTTPHEADER, [
    'x-api-key: your_secret_api_key'
]);

$response = curl_exec($ch);
curl_close($ch);

print_r(json_decode($response, true));
?>

🏗️ Project Structure

kilas/
├── public/                 # Frontend files
│   ├── css/               # Stylesheets
│   ├── js/                # JavaScript files
│   ├── images/            # Images and logo
│   └── *.html             # HTML pages
├── src/
│   ├── lib/               # Core libraries
│   │   ├── BaileysHandler.js    # WhatsApp connection handler
│   │   ├── SessionManager.js    # Multi-session management
│   │   ├── WebhookSender.js     # Webhook delivery system
│   │   └── MediaHandler.js      # Media file handler
│   ├── middleware/        # Express middleware
│   │   └── auth.js        # API authentication
│   ├── routes/            # API routes
│   │   ├── auth.js        # Authentication routes
│   │   ├── sessions.js    # Session management
│   │   ├── messages.js    # Message sending
│   │   ├── groups.js      # Group management
│   │   ├── contacts.js    # Contact management
│   │   ├── status.js      # Status updates
│   │   └── webhook.js     # Webhook configuration
│   └── websocket/         # WebSocket handlers
│       └── socketHandler.js
├── sessions/              # WhatsApp session data
├── media/                 # Saved media files
├── server.js              # Main server file
├── Dockerfile             # Docker configuration
├── docker compose.yml     # Docker Compose config
├── .env                   # Environment variables
└── package.json           # Dependencies

🛠️ Tech Stack

Backend: Node.js, Express.js
WebSocket: Socket.IO for real-time communication
WhatsApp: @whiskeysockets/baileys
Frontend: Vanilla JavaScript, Modern CSS with Glassmorphism
File Upload: Multer
Logging: Pino
HTTP Client: Axios (for webhooks)
QR Code: qrcode library

🤝 Contributing

We welcome contributions from the community! Here's how you can help:

Ways to Contribute

Report Bugs - Open an issue with detailed information
Suggest Features - Share your ideas for improvements
Submit Pull Requests - Fix bugs or add new features
Improve Documentation - Help make our docs better
Share Your Experience - Star the repo and spread the word!

Development Setup

# Fork and clone the repository
git clone https://github.com/dickyermawan/kilas.git
cd kilas

# Install dependencies
npm install

# Create .env file
cp .env.example .env

# Start development server
npm run dev

Pull Request Guidelines

Fork the repository
Create a feature branch (git checkout -b feature/amazing-feature)
Commit your changes (git commit -m 'Add amazing feature')
Push to the branch (git push origin feature/amazing-feature)
Open a Pull Request

Please ensure:

Code follows existing style conventions
All tests pass
Documentation is updated if needed
Commit messages are clear and descriptive

🐛 Troubleshooting

QR Code Not Appearing

Wait 30-60 seconds for QR generation
Check Live Events for "QR Code received" log
Ensure WebSocket is connected (green indicator in dashboard)

Session Not Connecting

Scan QR before it expires (~60 seconds)
Try deleting and recreating the session
Check browser console for errors
Verify WhatsApp app is updated to latest version

"Request Entity Too Large" Error

The server supports up to 50MB request body size
For larger files, consider compressing before sending
Recommended max file size: 10-15MB for optimal performance

Docker Container Issues

# Check container status
docker compose ps

# View logs
docker compose logs -f

# Restart container
docker compose restart

# Rebuild from scratch
docker compose down
docker compose up -d --build

API Returns 401 Unauthorized

Verify x-api-key header is included in request
Check API key matches value in .env
To disable auth, set API_KEY= (empty) in .env

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.

MIT License

Copyright (c) 2025 Dicky Ermawan S

Permission is hereby granted, free of charge, to any person obtaining a copy
of this software and associated documentation files (the "Software"), to deal
in the Software without restriction, including without limitation the rights
to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
copies of the Software, and to permit persons to whom the Software is
furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all
copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
SOFTWARE.

🙏 Acknowledgments

Built with Antigravity

This project was built with the assistance of Antigravity - Google DeepMind's advanced agentic coding AI. Antigravity helped accelerate development, improve code quality, and implement best practices throughout the project.

Special Thanks

@whiskeysockets/baileys - The amazing WhatsApp Web API library
Socket.IO - Real-time bidirectional event-based communication
Express.js - Fast, unopinionated web framework for Node.js
All Contributors - Thank you for making this project better!

📞 Support & Community

Issues: GitHub Issues
Discussions: GitHub Discussions
Email: [email protected]

🌟 Star History

If you find this project useful, please consider giving it a ⭐ on GitHub!

Made with ❤️ by Dicky Ermawan S

Powered by Antigravity 🚀

⬆ Back to Top

kilas

About kilas

Platforms

Languages

Links

README.md

Kilas - WhatsApp Gateway API

🚀 Modern, Fast & Reliable WhatsApp Gateway Built with Baileys

⚠️ Disclaimer

✨ Features

🎨 Beautiful Dashboard

🔌 Comprehensive API

🛡️ Enterprise Ready

🗄️ SQLite Data Persistence (NEW)

🔗 Integration Support

📸 Screenshots

Login Page

Live Events & Logs

Device Management

API Playground

Webhook Configuration

🚀 Quick Start

Prerequisites

Installation

Option 1: Manual Installation

Option 2: Using Docker Compose (Recommended)

First Steps

🐳 Docker Deployment

Option 1: Using Pre-built Image from Docker Hub (Recommended)

Option 2: Build from Source

Configuration

Data Persistence

Backup & Restore

Docker Commands

Environment Variables

🤖 n8n Integration

Installation

Features

Quick Start

Use Cases

Resources

📚 API Documentation

Authentication

📨 Messages API

Send Text Message

Send Quote/Reply Message

Start Typing Indicator

Stop Typing Indicator

Check Message Status

Send Image

Send Document

Send Location

👥 Sessions API

Get All Sessions

Create New Session

Delete Session

👨‍👩‍👧‍👦 Groups API

Get All Groups

Create Group

📇 Contacts API

Get All Contacts

📢 Status API

Post Status Update

🔔 Webhook API

Configure Webhook

Get Webhook Configuration

Test Webhook

Delete Webhook

🏗️ Project Structure

🛠️ Tech Stack

🤝 Contributing

Ways to Contribute

Development Setup

Pull Request Guidelines

🐛 Troubleshooting

QR Code Not Appearing

Session Not Connecting

"Request Entity Too Large" Error

Docker Container Issues

API Returns 401 Unauthorized
