mac_action_orchestrator
# Mac Action Orchestrator Local-first macOS action orchestrator with FastAPI + Uvicorn + Gemini planner. ## 1. Prerequisites - macOS - Python 3.10+ (recommended: 3.11 or 3.12) - `pip` available - Apple Vision Framework (built into macOS) for OCR - Xcode Command Line Tools (required for `swift` runtime): `xcode-select --install` Why 3.10+: - Python 3.9 is already EOL and may trigger warnings with newer `google-auth`. - System Python on older macOS may use LibreSSL, which can cause `urllib3` warnings. OCR note: - Vision OCR is executed through a Swift script (`Vision`/`AppKit`/`Foundation`). - On a fresh machine/session, the first OCR call may be noticeably slower due to cold-start compilation/loading, and this can cause the first run to fail (for example, OCR timeout). A retry usually succeeds once warmup is complete. ## 2. Setup In project root: ```bash cd /path/to/mac-action-orchestrator python3 -m venv .venv source .venv/bin/activate pip install -r requirements.txt --index-url https://pypi.org/simple ``` If you copied this project and `.venv` did not exist before, creating it is expected. ## 3. Config Use local-safe config - By default, no setting is required.: ```json { "host": "localhost", "user": "local", "remote_tmp_screen_path": "/tmp/agent_screen.png", "ssh_options": [], "rate_limit_seconds": 2 } ``` Current code is set to local execution mode for hackathon use. ## 4. Run ```bash source .venv/bin/activate uvicorn app:app --reload --port 8000 ``` Open a new terminal window: ```bash open -na "Google Chrome" --args --incognito http://127.0.0.1:8000 ``` (Open this URL in a **Chrome Incognito** window.) Permission note: - On first runs, macOS may show multiple permission dialogs. - Grant all required permissions (Accessibility, Screen Recording, Automation) before expecting stable end-to-end runs. - It is normal if the first few runs fail while permissions are still being approved. - In general, you cannot fully pre-grant these permissions from code before running; macOS requires user approval dialogs. - Permission setup guide (step-by-step for Terminal): `https://docs.google.com/document/d/1iAPZq1aGQyLF7jpY-fye3rQRxDQVX5VCJIG8thkapnE/edit?usp=sharing` Prompt examples: - `Open https://www.google.com in Chrome and then create a new tab, then move to the tab on the left, input wiki in this tab then search. On the results page, click the lowest (bottom-most) Wikipedia result visible on screen. No scrolling.` - `Open https://www.youtube.com/watch?v=5OR4c87Xt-E, and play the video from 00:30. Wait 5 seconds, than do next. ` - `Open https://www.wikipedia.org in Chrome, search for "Yosemite National Park", press Enter, wait for results, open the print dialog, click Save once, then press Enter to confirm saving as PDF. Wait 5 seconds, then stop.` - `Open https://en.wikipedia.org/wiki/Main_Page. Repeatedly scroll down one page. After each scroll, look for the visible text "Contact WikiPedia". As soon as it is visible, click it and stop scrolling.` (Max plan_again times should be set to 10 or more and you should have a solid API key) ## 5. First-time macOS permissions You may need to allow permissions for Terminal: - Accessibility - Screen Recording - Automation (System Events / Chrome, if prompted) Permission Guide: - Use this guide to complete macOS permission setup for Terminal/iTerm: `https://docs.google.com/document/d/1iAPZq1aGQyLF7jpY-fye3rQRxDQVX5VCJIG8thkapnE/edit?usp=sharing` - It explains what each permission is for and where to enable it in System Settings. Without these, actions or screen-size/screenshot related APIs can fail. ## 6. Run completion behavior: - After all actions finish, the app shows a completion dialog popup with final status and log name. - The full execution log is saved under `static/logs/` (for example: `static/logs/run_<timestamp>_<id>.txt`). - Example completion screenshot:  ## 7. Common errors and fixes 1. `source: no such file or directory: .venv/bin/activate` - You have not created venv yet. - Run: `python3 -m venv .venv` 2. `zsh: command not found: uvicorn` - Dependencies were not installed in the active venv. - Run: `source .venv/bin/activate && pip install -r requirements.txt` 3. `AssertionError: jinja2 must be installed` - `jinja2` missing. - Run: `pip install -r requirements.txt` (or `pip install jinja2`) 4. `ModuleNotFoundError` for Gemini / Google SDK - `google-genai` missing. - Run: `pip install -r requirements.txt` 5. `POST /api/screen_size` returns `500` - Usually macOS permissions issue, or running an old code version. - Check permissions listed in section 5. - Confirm you are on latest local-only code. 6. First OCR call is slow (or times out once) - This can happen on first run while Swift/Vision warms up. - Retry once; subsequent OCR calls are typically much faster. 7. Unexpected SSH password prompt - This means you are likely running an older remote-enabled version. - Pull latest code and restart server. ## 8. Security notes - Do not commit real API keys or machine-specific secrets. - Keep `config.json` local and sanitized. - Use `config.example.json` as template for sharing. ## 9. End-to-end example (planning + click logic) Example prompt: `Open https://www.google.com in Chrome and then create a new tab, then move to the tab on the left, input wiki in this tab then search. On the results page, click the lowest (bottom-most) Wikipedia result visible on screen. No scrolling.` What happens in this project: 1. Planner stage - You click `Run`. - `/api/plan_actions` sends your natural language prompt to Gemini. - Gemini returns structured batches/actions (not raw UI clicks yet), such as: - open URL - keyboard shortcuts (new tab / go to tab 1) - type text + enter - `plan_again` / `click_at` style actions for visual selection 2. Execution stage - The app runs actions locally via AppleScript/JXA. - After key steps (especially before visual clicks), it captures a fresh screenshot. - The run log is written to `static/logs/...` and shown in UI. 3. Click logic (important) - For click actions, the app does OCR on the latest screenshot and extracts visible text tokens with bounding boxes. - If the click target text is unique, it computes the center point and clicks directly. - If multiple matches exist, it enters disambiguation: - generates an annotated image (numbered/marked candidates; “draw circles/boxes” style targeting aid), - asks Gemini to choose the best candidate index using the screenshot + context prompt, - executes click on the chosen candidate center. - If page state is not ready or occluded, it may trigger a recovery branch (re-plan or occlusion resolution) and continue. 4. Why this is robust for “lowest Wikipedia result” - The instruction “bottom-most visible result” is treated as a visual grounding problem, not just text matching. - OCR tokens provide concrete on-screen candidates. - Candidate annotation + Gemini selection adds a second pass when simple exact match is ambiguous. - This reduces wrong clicks caused by duplicate text (e.g., multiple “Wikipedia” labels on one page). Tips for better reliability with this type of prompt: - Include constraints like `No scrolling`, `visible on screen`, `bottom-most`. - Keep target text explicit (`Wikipedia result`) rather than vague (`click that one`). - If there are repeated labels, include nearby context in prompt (for example: “in search results list, not top nav”).
